GDS Hardwire Charger with Male DC 5.5mm 34-70V DC Input 12V Output
RAM-GDS-CHARGE-V16U
In Stock: 1
This hardwire charger (RAM-GDS-CHARGE-V16U) is a 24VDC-60VDC swappable hardwire charger for the RAM Temp-Right heater module needing an upgrade in power compatibility.
- 24VDC-60VDC swappable hardwire charger for the RAM® Temp-Right™ heater module
- Backed by a 3-year warranty
(RAM-GDS-CHARGE-V16U)
Technical Specifications:
| Packaging Type | Poly Bag |
|---|---|
| Input Voltage | 24-60VDC |
| Output Voltage | 12VDC |
| Output Current | 7A max |
| Input Connector | SAE Connector |
| Input Cable Length | 1 Meter |
| Output Cable Length | 1 Meter |
| Operating Temperature | -10°C to +70°C |
| Storage Temperature | -20°C to +80°C |
| Regulatory | Over Voltage Protection Over Temperature Protection Short Circuit Protection Over Current (Input) Protection Over Load Protection Auto Recovery RoHS Compliance WEEE Compliance FCC, CE |
| Certifications | RCM Certification |
Product Information
| SKU | RAM-GDS-CHARGE-V16U |
|---|---|
| Barcode | 793442007262 |
| Brand | RAM Mounts |
| Weight | 0.3470 kg |
