GDS Modular 10-30V Hardwire Charger with Type-C 2.0 Cable
RAM-GDS-CHARGE-USBC-V7B1-1U
RRP $99.00
In Stock: 50+
The GDS Modular 10-30V Hardwire Charger with Type-C 2.0 Cable (RAM-GDS-CHARGE-USBC-V7B1-1U) connects to a power source and provides power to any GDS vehicle solution. When it comes time to upgrade, the quick disconnect feature enables you to avoid any rewiring by unplugging the power connector and attaching the new charger components. Compatible with any 5V device with a current requirement of 2.5A or less. The previous part was RAM-GDS-CHARGE-USBC-V7B1U, which did not come with the RAM-GDS-CAB-CLAMP2U (this new part does).
Key Features:
- Hardwire charger features USB Type-A female connector
- Comes with GDS® Genuine USB Type-C 2.0 Cable; featuring USB Type-A male connection and USB Type-C male connection
- When upgrading devices, avoid rewiring by unplugging power connector and attaching new charger components
- Part of the GDS® Ecosystem™ to keep devices protected, connected, and charged in nearly any application
- Backed by a 3-year warranty
(RAM-GDS-CHARGE-USBC-V7B1-)
Instructions
Instructions for Modular Hardwire Charger
GDS Hardwire 10-30V Charger Female USB-A
RAM-GDS-CHARGE-V7B1U
GDS USB Type C 2.0 Cable
RAM-GDS-CAB-USBC-AMCMU-1
GDS USB Type-A Clamp
RAM-GDS-CAB-CLAMP2U
Technical Specifications:
| Hardware Included | (1) USB Type-C to Type-A 2.0 Cable |
|---|---|
| Packaging Type | Poly Bag |
| Input Voltage | 10-30VDC |
| Output Voltage | 5-9VDC* |
| Output Current | 2.5A max |
| Input Connector | USB Type-C |
| Input Cable Length | 1.2 Meters including 2 Pole Flat Marine Connector |
| Output Cable Length | .2 Meter |
| Operating Temperature | -10°C to +70°C |
| Storage Temperature | -40°C to +70°C |
| Regulatory | Over Voltage Protection Short Circuit Protection Reverse Polarity Protection RoHS Compliance WEEE Compliance SAE J-1113-5 Load Dump (Transient Voltage) Moisture Resistant FCC, CE, UKCA, IC |
| Certifications | E-Mark Certification RCM Certification IEC/UL 62368-1 |
Product Information
| SKU | RAM-GDS-CHARGE-USBC-V7B1-1U |
|---|---|
| Barcode | 793442024269 |
| Brand | RAM Mounts |
| Weight | 0.24 kg |
| Warranty | 3 year warranty |
