The RAM Tough-Mag Heavy Duty Magnetic Mount with Diamond Plate - Medium (RAM-138-MAG88U) features a medium length double socket arm, one 2.43" x 1.31" diameter diamond base, and one RAM Tough-Mag base. This heavy duty magnetic solution features C size components from our patented rubber ball and socket system, allowing the system to adjust at both ends of the socket arm. The rubber ball and socket technology allows for almost infinite adjustment to provide ideal viewing angles and dampens shock and vibration to extend the life of your device.The RAM Tough-Mag features 10 industrial-strength N52 grade magnets that magnetize to any ferrous metal surface and rubber coating that protects the metal surface you're attaching to.

Key Features:
  • Magnetic or drill-down mounting solution; secure your device to one end and the other to your preferred surface
  • Includes one diamond ball base, one Tough-Mag™ base, and one C size medium length double socket arm; ball and socket technology allows for near-infinite adjustability
  • RAM® Tough-Mag™ 88mm base magnetizes to any ferrous metal surface
  • Made of powder-coated, marine-grade aluminum for durability and reliability in the most demanding environments
  • Backed by a lifetime warranty

(RAM-138-MAG88U)

Technical Specifications:

Product DimensionsOverall Height: 7.67" (19.48 cm)
Socket To Socket Length4.66" (11.84 cm)
Hole Pattern2-Hole AMPS 1.912"
Plate SizeTop Plate: 2.43" (61.7 mm) x 1.31" (33.3 mm) Diameter
Magnetic Base: 3.46" (87.9 mm) Diameter
Ball SizeC Size (1.5")
Weight CapacityStandard Use: 4 lbs (1.81 kg)
Heavy-Duty Use: 3 lbs (1.36 kg)
MaterialsMarine-grade aluminum
N52 Magnets (Qty 10)
Packaging TypePoly Bag

Product Information

SKU RAM-138-MAG88U
Barcode 793442025129
Brand RAM Mounts
Weight 0.67 kg
Warranty RAM Mounts components are generally covered by a lifetime warranty against manufacturing defects. Electronic items (and docks and parts containing electronic components) are typically covered by a 3-year warranty. Some items are considered general wear, such as suction cups, foam pads, rubber feet etc.
