Tab-Tite™ Holder for 10.1" - 10.5" Tablets with or without Case
RAM-HOL-TAB33U
In Stock: 20+
The RAM Tab-Tite spring-loaded, quick release holder offers a secure fit with easy access to the mounted 9"-10"tablet. The spring-loaded design makes it easy to insert and remove your tablet, while keeping it secure in a variety of applications. The custom end cups are designed to optimize the functionality of your tablet, enabling access to all buttons, ports, and tablet functions. Included is a set of four nuts and bolts to attach the holder to any RAM components that contain the universal AMPS hole pattern. The RAM Tab-Tite holder is compatible with any tablet within the listed dimensions.
Height Range: 9.55"【24 cm】 - 11.8"【30 cm】
Width Range: 5.5"【14 cm】 - 6.95"【18 cm】
Depth Range: .2"【5 mm】 - .66"【1,7 cm】 max
- Spring-loaded holder secures the Samsung Tab (S6 Lite, A7 10.4, S5e, and A 10.1) and Lenovo K10 Tablet with or without case; interchangeable end cups allow you to modify the holder when upgrading devices
- Compatible with RAM® round ball bases for attaching a double socket arm; ball and socket technology allows for near-infinite adjustability
- Made of high-strength composites for durability and reliability in the most demanding environments
- Backed by a lifetime warranty
(RAM-HOL-TAB33U)
Technical Specifications:
| Hardware Included | Assembly Hardware (4) #8-32 x 5/8" Machine Screws (4) #8-32 x 1/2" Machine Screws (4) #8-32 Nyloc Nuts |
|---|---|
| Holder Dimensions | Height Range: 9.55" (24.26 cm) - 11.8" (29.97 cm) Width Range: 5.5" (13.97 cm) - 6.95" (17.65 cm) Depth Range: .2" (0.51 cm) - .66" (1.68 cm) max |
| Hole Pattern | 4-Hole AMPS: 1.181" x 1.496" |
| Materials | High strength composite |
| Packaging Type | Poly Bag |
Product Information
| SKU | RAM-HOL-TAB33U |
|---|---|
| Barcode | 793442101410 |
| Brand | RAM Mounts |
| Weight | 0.49 kg |
| Warranty | RAM Mounts components are generally covered by a lifetime warranty against manufacturing defects. Electronic items (and docks and parts containing electronic components) are typically covered by a 3-year warranty. Some items are considered general wear, such as suction cups, foam pads, rubber feet etc. |
